Ce:YAG

Current Position: Home » Products » Ce:YAG
Ce:YAG

Ce: YAG crystal (chemical formula Ce: Y3Al5O12, also known as cerium-doped yttrium aluminum garnet crystal) is a scintillation crystal with excellent scintillation performance, which is widely used in scientific research and industrial high-energy ray detection.  Ce: YAG crystal shows strong absorption peaks in the X-ray band and extreme ultraviolet band, and the emission wavelength is in the range area of 500-600nm, which is well matched with the receiving sensitive wavelength of ordinary photomultiplier tubes (PMT) and silicon photodiodes (PD).

Ce: YAG shows stable physical and chemical properties, high thermal conductivity, and resistance to harsh operating environments. It exhibits excellent scintillating characteristics, such as high scintillating efficiency, high light yield, and fast decay time (about 70ns). Ce: YAG crystals or Ce: YAG ceramics are widely used in photomultiplier tubes, photoelectric counters, scintillation screens and other devices.  Which is used to detect high-energy particles, such as alpha particles, β rays, extreme ultraviolet, etc.  Because of the excellent scintillation performance of Ce:YAG crystal, it is widely used in CT, scanning electron microscope and other equipment. In particular, Ce:YAG single crystal can prepare to thin screens with a thickness of less than 30 um, which plays an important role in X-ray scintillator screens.



Features Applications
  • High energy resolution
  • Chemically inert
  • High thermal conductivity
  • High mechanical strength
  • Fast decay time
  • High sensitivity
  • Excellent scintillating efficiency
  • X-ray, β-ray detection
  • Photomultiplier tube
  • Photoelectric counter
  • Scintillation Screen
  • LED lighting field

MATERIAL PROPERTIES

Chemical formulaCe:Y3Al5O12
Desity (g/cm3)4.55
Melting point (℃)1970
Hardness (Mho)8.5
HygroscopicNo
ClesvageNo
Solubility (g/100gH2O)N/A
Thermal expansion coeff (C-1)8.5*10-6

SCINTILLATOR PROPERTIES

Wavelength(Max. Emission)(nm)550
Wavelength range(nm)500-700
Decay time(ns)70
Light yield(Photons/Mev)9000-14000
Refractive index(Max. Emission)1.82
Radiation length(cm)3.5
Transmittance(%) TBA
Optical transmittance(um) TBA
Reflection loss/surface(%) TBA
Energy resolution(%)7.5
Photoelectron yield [% of NaI(Tl)](for Υ-rays)35
Neutron capture cross-section(barms) TBA

Dia 44X2 mm Ce:YAG crystal Radiation source:X-ray (4W, 50KV)Silver Ag

Dia 44X2 mm Ce:YAG crystal Radiation source:X-ray (4W, 50KV)Silver Ag
Dia 44X2 mm Ce:YAG crystal Radiation source:X-ray (4W, 50KV)Silver Ag

Dia 60×0.1 mm Ce:YAG crystal Uniformity Characterization of Light Output The variation range is less than 1%

X-Ray excited luminescence curve
X-Ray excited luminescence curve
Light output curve & Energy resolution curve
Light output curve & Energy resolution curve

X-Ray Tube, High Voltages power Supply and usb Controller (4w,50KV)

MINI-X2 Miniature X-Ray Tube, High Voltages power Supply and usb Controller (4w,50KV)(Silver Ag)
MINI-X2 Miniature X-Ray Tube, High Voltages power Supply and usb Controller (4w,50KV)(Silver Ag)-2
MINI-X2 Miniature X-Ray Tube
High Voltages power Supply
Usb Controller (4w,50KV)(Silver Ag)

Related application(s) with Ce:YAG:

X-ray detection γ-ray detection

Medical CT

If you are intereted in Ce:YAG, please click the button below to enquire or ask for a samplel.
